BYD Seal
DIMENSIONS
BYD Seal
Dynamic RWD
Dimensions
Overall Length (mm)
4,800
Overall Width (mm)
1,875
Overall Height (mm)
1,460
Wheel Track Front and Rear (mm)
1,620 / 1,625
Wheelbase (mm)
2,920
Minimum turning radius (m)
5.7
Ground Clearance Unladen (mm)
120
Front luggage capacity (L)
50
Rear trunk capacity (L)
400
Kerb Weight (kg)
1,922
Gross Vehicle Mass (kg)
2,344
Premium RWD
Dimensions
Overall Length (mm)
4,800
Overall Width (mm)
1,875
Overall Height (mm)
1,460
Wheel Track Front and Rear (mm)
1,620 / 1,625
Wheelbase (mm)
2,920
Minimum turning radius (m)
5.7
Ground Clearance Unladen (mm)
120
Front luggage capacity (L)
50
Rear trunk capacity (L)
400
Kerb Weight (kg)
2,055
Gross Vehicle Mass (kg)
2,501
AWD Performance
Dimensions
Overall Length (mm)
4,800
Overall Width (mm)
1,875
Overall Height (mm)
1,460
Wheel Track Front and Rear (mm)
1,620 / 1,625
Wheelbase (mm)
2,920
Minimum turning radius (m)
5.7
Ground Clearance Unladen (mm)
120
Front luggage capacity (L)
50
Rear trunk capacity (L)
400
Kerb Weight (kg)
2,185
Gross Vehicle Mass (kg)
2,631
BYD Seal
Dynamic RWD
Traction Motor
Drivetrain
Rear Wheel Drive
Front motor type
Front motor maximum power (kW)
Front motor maximum torque (N·m)
Rear motor type
Permanent magnet synchronous motor
Rear motor maximum power (kW)
150
Rear motor maximum torque (N·m)
310
Maximum power (kW)
150
Maximum torque (N·m)
310
Premium RWD
Traction Motor
Drivetrain
Rear Wheel Drive
Front motor type
Front motor maximum power (kW)
Front motor maximum torque (N·m)
Rear motor type
Permanent magnet synchronous motor
Rear motor maximum power (kW)
230
Rear motor maximum torque (N·m)
360
Maximum power (kW)
230
Maximum torque (N·m)
360
AWD Performance
Traction Motor
Drivetrain
Four-Wheel Drive
Front motor type
Asynchronous Motor
Front motor maximum power (kW)
160
Front motor maximum torque (N·m)
310
Rear motor type
Permanent magnet synchronous motor
Rear motor maximum power (kW)
230
Rear motor maximum torque (N·m)
360
Maximum power (kW)
390
Maximum torque (N·m)
670
BYD Seal
Dynamic RWD
Performance
Acceleration 0-100km/h (s)
7.5
Electric range: NEDC Combined Cycle (km)
510
Seating capacity
5
Battery type
BYD Blade Battery (LFP)
Battery capacity (kWh)
61.44
Premium RWD
Performance
Acceleration 0-100km/h (s)
5.9
Electric range: NEDC Combined Cycle (km)
650
Seating capacity
5
Battery type
BYD Blade Battery (LFP)
Battery capacity (kWh)
82.56
AWD Performance
Performance
Acceleration 0-100km/h (s)
3.8
Electric range: NEDC Combined Cycle (km)
580
Seating capacity
5
Battery type
BYD Blade Battery (LFP)
Battery capacity (kWh)
82.56
BYD Seal
Dynamic RWD
Chassis
Front suspension
Double Wishbone
Rear suspension
Multi-Link
Frequency Selective Damping (FSD) shock absorbers
-
Front disc brake
Ventilated
Rear disc brake
Ventilated
Front brake caliper
Floating
Wheel Type
Alloy
Tyre Size
225/50 R18
Premium RWD
Chassis
Front suspension
Double Wishbone
Rear suspension
Multi-Link
Frequency Selective Damping (FSD) shock absorbers
-
Front disc brake
Ventilated + Drilled
Rear disc brake
Ventilated
Front brake caliper
Fixed
Wheel Type
Alloy
Tyre Size
235/45 R19
AWD Performance
Chassis
Front suspension
Double Wishbone
Rear suspension
Multi-Link
Frequency Selective Damping (FSD) shock absorbers
Front + Rear
Front disc brake
Ventilated + Drilled
Rear disc brake
Ventilated
Front brake caliper
Fixed
Wheel Type
Alloy
Tyre Size
235/45 R19
BYD Seal
Dynamic RWD
New Energy
AC charging port - Type 2 (7kW)
Portable charging cable (mode 2)
DC Charging Port - CCS 2 (110kW)
DC Charging Port - CCS 2 (150kW)
-
V2L function
V2L discharge adapter
Regenerative Braking
Premium RWD
New Energy
AC charging port - Type 2 (7kW)
Portable charging cable (mode 2)
DC Charging Port - CCS 2 (110kW)
-
DC Charging Port - CCS 2 (150kW)
V2L function
V2L discharge adapter
Regenerative Braking
AWD Performance
New Energy
AC charging port - Type 2 (7kW)
Portable charging cable (mode 2)
DC Charging Port - CCS 2 (110kW)
-
DC Charging Port - CCS 2 (150kW)
V2L function
V2L discharge adapter
Regenerative Braking
BYD Seal
Dynamic RWD
Safety and Security
Front airbags - driver & front passenger
Side airbags - driver & front passenger
Side curtain airbags - front & rear
Far-side airbags - driver
Side airbags - rear
Dual stage pretensioner on front seat belts
Pretensioner on rear seat belts
Seat belt reminder - front & rear
360° Camera
Front Parking Sensor (2 Zones)
Rear Parking Sensor (4 Zones)
ISOFIX Child restraint anchorage points
Electronic child lock
-
Intelligent power brake system
Electric Power Steering (DP-EPS)
Traction Control System (TCS)
Electronic Brake Force Distribution (EBD)
Hill Hold Control (HHC)
Auto-hold
Adaptive Cruise Control (ACC)
Automatic Emergency Braking (AEB)
Lane Departure Warning (LDW)
Lane Departure Prevention (LDP)
Emergency Lane Keeping Assist (ELK)
Predictive Collision Warning (PCW)
Intelligent Cruise Control (ICC)
Rear Collision Warning (RCW)
TrafficSign Recognition (TSR)
Intelligent Speed Limit Information (ISLI)
Intelligent Speed Limit Control (ISLC)
Front Cross Traffic Alert (FCTA)
Front Cross Traffic Brake (FCTB)
Rear Cross Traffic Alert (RCTA)
Rear Cross Traffic Brake (RCTB)
Blind Spot Detection (BSD)
Door Open Warning (DOW)
High Beam Assist(HMA)
Driver Attention Warning(DAW)
Head Up Display (W-HUD)
-
Intelligence Torque Adaption Control（ITAC）
-
Premium RWD
Safety and Security
Front airbags - driver & front passenger
Side airbags - driver & front passenger
Side curtain airbags - front & rear
Far-side airbags - driver
Side airbags - rear
Dual stage pretensioner on front seat belts
Pretensioner on rear seat belts
Seat belt reminder - front & rear
360° Camera
Front Parking Sensor (2 Zones)
Rear Parking Sensor (4 Zones)
ISOFIX Child restraint anchorage points
Electronic child lock
-
Intelligent power brake system
Electric Power Steering (DP-EPS)
Traction Control System (TCS)
Electronic Brake Force Distribution (EBD)
Hill Hold Control (HHC)
Auto-hold
Adaptive Cruise Control (ACC)
Automatic Emergency Braking (AEB)
Lane Departure Warning (LDW)
Lane Departure Prevention (LDP)
Emergency Lane Keeping Assist (ELK)
Predictive Collision Warning (PCW)
Intelligent Cruise Control (ICC)
Rear Collision Warning (RCW)
TrafficSign Recognition (TSR)
Intelligent Speed Limit Information (ISLI)
Intelligent Speed Limit Control (ISLC)
Front Cross Traffic Alert (FCTA)
Front Cross Traffic Brake (FCTB)
Rear Cross Traffic Alert (RCTA)
Rear Cross Traffic Brake (RCTB)
Blind Spot Detection (BSD)
Door Open Warning (DOW)
High Beam Assist(HMA)
Driver Attention Warning(DAW)
Head Up Display (W-HUD)
Intelligence Torque Adaption Control（ITAC）
-
AWD Performance
Safety and Security
Front airbags - driver & front passenger
Side airbags - driver & front passenger
Side curtain airbags - front & rear
Far-side airbags - driver
Side airbags - rear
Dual stage pretensioner on front seat belts
Pretensioner on rear seat belts
Seat belt reminder - front & rear
360° Camera
Front Parking Sensor (2 Zones)
Rear Parking Sensor (4 Zones)
ISOFIX Child restraint anchorage points
Electronic child lock
Intelligent power brake system
Electric Power Steering (DP-EPS)
Traction Control System (TCS)
Electronic Brake Force Distribution (EBD)
Hill Hold Control (HHC)
Auto-hold
Adaptive Cruise Control (ACC)
Automatic Emergency Braking (AEB)
Lane Departure Warning (LDW)
Lane Departure Prevention (LDP)
Emergency Lane Keeping Assist (ELK)
Predictive Collision Warning (PCW)
Intelligent Cruise Control (ICC)
Rear Collision Warning (RCW)
TrafficSign Recognition (TSR)
Intelligent Speed Limit Information (ISLI)
Intelligent Speed Limit Control (ISLC)
Front Cross Traffic Alert (FCTA)
Front Cross Traffic Brake (FCTB)
Rear Cross Traffic Alert (RCTA)
Rear Cross Traffic Brake (RCTB)
Blind Spot Detection (BSD)
Door Open Warning (DOW)
High Beam Assist(HMA)
Driver Attention Warning(DAW)
Head Up Display (W-HUD)
Intelligence Torque Adaption Control (ITAC)
BYD Seal
Dynamic RWD
Exterior
Silver-plated panoramic glass roof
Electronic hidden door handles
Rear windscreen mount antenna
One-touch open/close tailgate
Electrically heated and adjustable exterior mirrors
Electrically retractable exterior mirrors
Door mirror auto-tilt
-
Door mirror position memory
-
Auto windows with anti-trap
Soundproof double glazed glass - windsheild and front door
Rear windscreen with electric heating and defrosting
Premium RWD
Exterior
Silver-plated panoramic glass roof
Electronic hidden door handles
Rear windscreen mount antenna
One-touch open/close tailgate
Electrically heated and adjustable exterior mirrors
Electrically retractable exterior mirrors
Door mirror auto-tilt
Door mirror position memory
Auto windows with anti-trap
Soundproof double glazed glass - windsheild and front door
Rear windscreen with electric heating and defrosting
AWD Performance
Exterior
Silver-plated panoramic glass roof
Electronic hidden door handles
Rear windscreen mount antenna
One-touch open/close tailgate
Electrically heated and adjustable exterior mirrors
Electrically retractable exterior mirrors
Door mirror auto-tilt
Door mirror position memory
Auto windows with anti-trap
Soundproof double glazed glass - windsheild and front door
Rear windscreen with electric heating and defrosting
BYD Seal
Dynamic RWD
Interior
Steering wheel mounted controls - Audio, phone, ACC and Multi-Function display
Imitation leather-wrapped steering wheel
Genuine leather-wrapped steering wheel
-
10.25-inch LCD instrumentation
Centre console storage compartment
Imitation leather-wrapped seats
Genuine leather-wrapped seats
-
Driver seat 8-way power adjustable
Driver seat 4-way lumber power adjustment
-
Passenger seat 6-way power adjustable
Front seats ventilated & heated
Driver seat with position memory
-
Courtesy seating
-
Vice dashboard with dual cup holders
Front height-adjustable cap holder
Rear row central armrest (with dual cup holders)
Automatic anti-dazzle interior rearview mirror
Rain sensing frameless wipers
Metal door sill protectors
Front sunvisor with vanity mirror & lighting
Premium RWD
Interior
Steering wheel mounted controls - Audio, phone, ACC and Multi-Function display
Imitation leather-wrapped steering wheel
-
Genuine leather-wrapped steering wheel
10.25-inch LCD instrumentation
Centre console storage compartment
Imitation leather-wrapped seats
-
Genuine leather-wrapped seats
Driver seat 8-way power adjustable
Driver seat 4-way lumber power adjustment
Passenger seat 6-way power adjustable
Front seats ventilated & heated
Driver seat with position memory
Courtesy seating
Vice dashboard with dual cup holders
Front height-adjustable cap holder
Rear row central armrest (with dual cup holders)
Automatic anti-dazzle interior rearview mirror
Rain sensing frameless wipers
Metal door sill protectors
Front sunvisor with vanity mirror & lighting
AWD Performance
Interior
Steering wheel mounted controls - Audio, phone, ACC and Multi-Function display
Imitation leather-wrapped steering wheel
-
Genuine leather-wrapped steering wheel
10.25-inch LCD instrumentation
Centre console storage compartment
Imitation leather-wrapped seats
-
Genuine leather-wrapped seats
Driver seat 8-way power adjustable
Driver seat 4-way lumber power adjustment
Passenger seat 6-way power adjustable
Front seats ventilated & heated
Driver seat with position memory
Courtesy seating
Vice dashboard with dual cup holders
Front height-adjustable cap holder
Rear row central armrest (with dual cup holders)
Automatic anti-dazzle interior rearview mirror
Rain sensing frameless wipers
Metal door sill protectors
Front sunvisor with vanity mirror & lighting
BYD Seal
Dynamic RWD
Entertainment
FM Radio
*Apple CarPlay® (USB) and Android Auto™ (wireless)
*Bluetooth® phone connectivity and audio streaming
15.6 Inch intelligent Rotating touch screen display
DYNAUDIO, 12 speakers
Voice assistant - Thai
*Satellite navigation
*Music streaming
1 x USB-C & 1 x USB-A, Front
1 x USB-C & 1 x USB-A, Rear
OTA updates
Premium RWD
Entertainment
FM Radio
*Apple CarPlay® (USB) and Android Auto™ (wireless)
*Bluetooth® phone connectivity and audio streaming
15.6 Inch intelligent Rotating touch screen display
DYNAUDIO, 12 speakers
Voice assistant - Thai
*Satellite navigation
*Music streaming
1 x USB-C & 1 x USB-A, Front
1 x USB-C & 1 x USB-A, Rear
OTA updates
AWD Performance
Entertainment
FM Radio
*Apple CarPlay® (USB) and Android Auto™ (wireless)
*Bluetooth® phone connectivity and audio streaming
15.6 Inch intelligent Rotating touch screen display
DYNAUDIO, 12 speakers
Voice assistant - Thai
*Satellite navigation
*Music streaming
1 x USB-C & 1 x USB-A, Front
1 x USB-C & 1 x USB-A, Rear
OTA updates
BYD Seal
Dynamic RWD
Light
LED headlight
Follow me home headlight
LED daytime running light
LED tailight light
Rear fog light
Sequential rear indicators
LED centre high mount stop light
RGB dynamic mood lights with rhythm function
LED front reading light
LED rear side reading light
Luggage compartment light
Premium RWD
Light
LED headlight
Follow me home headlight
LED daytime running light
LED tailight light
Rear fog light
Sequential rear indicators
LED centre high mount stop light
RGB dynamic mood lights with rhythm function
LED front reading light
LED rear side reading light
Luggage compartment light
AWD Performance
Light
LED headlight
Follow me home headlight
LED daytime running light
LED tailight light
Rear fog light
Sequential rear indicators
LED centre high mount stop light
RGB dynamic mood lights with rhythm function
LED front reading light
LED rear side reading light
Luggage compartment light
BYD Seal
Dynamic RWD
Comfort & Convenience
Keyless entry & start
NFC card key
Wireless phone charger x 2
12V accessory socket
PM2.5 filtration system
PM2.5 high efficiency filter (CN95)
Negative ion air purifier
Automatic dual-zone heat pump air-conditioning
Rear central air vents
Tyre repair kit
Tool kit
Premium RWD
Comfort & Convenience
Keyless entry & start
NFC card key
Wireless phone charger x 2
12V accessory socket
PM2.5 filtration system
PM2.5 high efficiency filter (CN95)
Negative ion air purifier
Automatic dual-zone heat pump air-conditioning
Rear central air vents
Tyre repair kit
Tool kit
AWD Performance
Comfort & Convenience
Keyless entry & start
NFC card key
Wireless phone charger x 2
12V accessory socket
PM2.5 filtration system
PM2.5 high efficiency filter (CN95)
Negative ion air purifier
Automatic dual-zone heat pump air-conditioning
Rear central air vents
Tyre repair kit
Tool kit
หมายเหตุ*
- The real Range is influenced by many factors such as individual driving style, load, traffic etc. The declared range is estimated for reference only.
- Bluetooth® is a registered trademark of Bluetooth SIG, Inc. Compatibility and functionality variesdepending on device.
- Apple CarPlay® is a registered trade mark of Apple Inc.
- Android Auto™ is a registered trade mark of Google Inc.
- Dirac HD sound® is a registered trade mark of Dirac Research AB .
- Colours depicted are a guide only and may vary from actual colours due to the printing.
- Driving assist system are not a substitute for the driver’s responsibility of the vehicle.
- BYD reserves the right to vary vehicle specifications and standard features from those detailed in this brochure.
Get Ready
Quantum Black
Still not ready?
If you are still not sure, get to know us more.
READY TO DOWNLOAD
Meet our application today
A tool that allows you to discover a new driving experience that is efficient and seamless anywhere, anytime.
